Description
Hammer Mill
Built for extreme durability and precision, this complete, ready-to-run Hammer Mill is designed to tackle heavy-duty processing with ease.
Key Features
-
Heavy-Duty Construction: All-steel construction, proudly made in the USA.
-
Precision Engineering: CNC manufactured high-carbon steel built to extreme tolerances.
-
Adjustable Output: Complete control over processed material size, ranging from #30 mesh down to an ultra-fine #400 mesh. Processes up to 4.5″ rock into #300 powder.
-
Strike Force Hammers: Includes (14) new 5/8″ bolt-on, high-carbon tool steel hammers. These are 50% larger and easily replaceable with basic hand tools.
-
Reliable Hardware: Features a 1.625″ main axle shaft and fully sealed industrial bearings (with grease fittings) for years of trouble-free use.
-
Adjustable Stand: Includes (4) removable 2″ square tubing legs with steel bolt-down plates, fully adjustable for uneven ground.
-
Industrial Finish: Powder-coated for superior protection and longevity.
-
Discharge: Dual (2) high-volume 3.25″ stainless steel discharge tubes.
-
Weight: 375 lbs.
Power & Drive
-
Engine: High Output HD HP Honda Industrial Engine (Electric start optional).
-
Drive System: ASV (Adjustable Speed Variable) drive allows you to easily change the hammer swing speed.
Mini Primary Trommel
A highly versatile and capable primary trommel designed to handle serious volume while remaining easily configurable for your specific site needs. Wheeled or skid-based units are available upon request.
General Specifications
| Specification | Details |
| Overall Dimensions | 95″ L x 28″ W x 42″ H (2,413 x 711 x 1,066 mm) |
| Operating Weight | 650 lbs (295 kg) (Depends on options) |
| Standard Feed Hopper | 22” x 25” (558 x 635 mm) – Dump area |
| Barrel Diameter | 15” (381 mm) |
| Screen Barrel Length | 36” (914 mm) |
| Scrubber Barrel Length | 24” (609 mm) |
| Barrel Speed | Variable |
| Water Requirements | 230 US-GPM Minimum (380+ US-GPM Preferred) |
| Standard Gold Sluice | 7′ L x 12″ W (2,136 x 304 mm) |
| Schedule B Code | 8474.10.0010 |
Power Configurations
-
Gas / Petrol: Briggs or Honda.
-
Diesel: Yanmar, Hatz, Kubota, or Kohler.
-
Electric: 230 / 120v single phase (50 or 60 Hz compatible). Requires a 4,500-watt generator minimum.
Optional Upgrades & Accessories
| Upgrade Option | Price (USD) |
| Mechanical Feed Hopper (For Mini-Excavators/Backhoes) | $1,490 |
| Clay-Buster Feed Hopper | $1,490 |
| Small Road-Worthy Trailer Mount | $2,290 |
| Secondary “Wider Add-On” 5′ Sluice (Converts to 2-piece/Multi-Stage) | $1,350 |
| Dredge Hose Adapter (3-inch) | $680 |
| Honda Motor Upgrade (For gas-driven models only) | $309 |
| Pan-American Duplex Jig (Diamond/Gemstone – 12″x12″, 2-3 Y³/Hr) | Contact for Pricing |
Reverse Helix Trommel Secondary
Designed to maximize fine gold recovery, this secondary system automates the tedious panning process.
The Extraction Process
-
Initial Wash: Material is added to the hopper where it receives an initial wash.
-
The Reverse Helix: Washed material flows into the 33-inch long, 7-inch wide barrel containing a 45-foot Reverse Helix Screw. This design provides maximum processing time to capture all gold.
-
Continuous Slurry: Inside the barrel, a full-length spray bar continuously washes the material, keeping it in a slurry.
-
Separation: Lighter material washes out the back into a waste bucket. Heavier, valuable material stays caught in the grooves of the reverse helix screw and is forced to the front.
-
Spiral Wheel Finishing: Heavy material drops from the trommel mouth directly into a standard 12″ Desert Fox Spiral wheel.
-
Final Polish: The spiral wheel slowly and meticulously washes away black sand and unwanted materials, moving the pure gold up the riffles and safely into the collection cup.
Optional Mill Table
Add a heavy-duty mill table to complete your setup.
| Size | Capacity | Motor | Weight |
| 2′ x 4′ | 500 – 600 lbs/hr | 1/2 HP (110V, Single Phase) | 600 lbs |
